Steel coil sheet slitting machine is consists of uncoiler, feeder, pinch, pre-leveler, cropping shear, slitter, scrap winder and recoiler, etc. It is used for slitting the wide raw coil into narrow strips in order to prepare material for subsequent processes as milling, pipe welding, cold forming, punch forming, etc. Moreover, this line can alse slitvarious non ferrous metal coils by changing slitting tools of different materials.
Is there a problem? Please contact us to serve you!
Steel coil sheet slitting machine is consists of uncoiler, feeder, pinch, pre-leveler, cropping shear, slitter, scrap winder and recoiler, etc. It is used for slitting the wide raw coil into narrow strips in order to prepare material for subsequent processes as milling, pipe welding, cold forming, punch forming, etc. Moreover, this line can alse slitvarious non ferrous metal coils by changing slitting tools of different materials.
HR coil slitting line machine is consists of uncoiler, feeder, pinch, pre-leveler, cropping shear, slitter, scrap winder and recoiler, etc. It is used for slitting the wide raw coil into narrow strips in order to prepare material for subsequent processes as milling, pipe welding, cold forming, punch forming, etc. Moreover, this line can alse slitvarious non ferrous metal coils by changing slitting tools of different materials.
f you want to know more details about this slitting machine, you can consult us via email: [email protected] or WhatsApp: 0086 13921996208. And welcome to visit Saibo factory.
| Model | 1-6X2000mm | 2-8X2000mm | 3-12X2200mm | 4-16X2200mm |
| Thickness | 1-6mm | 2- 8mm | 3-12mm | 4-16mm |
| Width | 900-2000mm | 900-2000mm | 900-2200mm | 900-2200mm |
| Coil weight | 30T | 30T | 35T | 35T |
| Finish width | ≥ 50mm | ≥ 70mm | ≥ 80mm | ≥ 100mm |
| Slitting strips | ≤ 10 | ≤ 8 | ≤ 7 | ≤ 5 |
| Slitting speed | 0-50m/min | 0-40m/min | 0-30m/min | 0-25m/min |
| Occupied area | 28 X 11m | 30 X 11m | 35 X 11m | 38 X 11m |
| Power | 320kw | 340kw | 480kw | 650kw |
The price of the equipment depends on various factors such as profile specifications, thickness, and additional features. Could you please provide us with more details about your specific requirements, so we can provide you with an accurate price?
We offer a standard warranty period for our equipment, which typically ranges from one year. However, the exact warranty period may vary depending on the specific equipment model. We can provide you with detailed information regarding the warranty coverage for the equipment you are interested in.
Yes, we ensure that spare parts for our equipment are readily available. We maintain a comprehensive inventory of spare parts to minimize downtime in case of any maintenance or repairs. Additionally, we offer after-sales support and can assist you in procuring any necessary spare parts in a timely manner. Like CZ purlin roll forming machine, decking sheet roll forming machines, Stud and Track roll forming machines and so on. Sure, like some rollers need produce depend on order only. It will take 3-7 days. We will try best give you early.
Yes, we provide comprehensive training for operating the equipment. Our team of experts will guide you through the installation process and provide hands-on training to ensure that you and your staff are familiar with the equipment’s operation, maintenance, and safety procedures.
The inclusion of installation services may vary depending on the specific equipment and the location of the installation. We can discuss the installation options available and provide you with a detailed quotation that specifies whether installation is included or if it will incur additional charges.
Yes, our equipment can be customized to meet specific customer requirements. We can discuss your customization needs and work closely with our engineering team to develop a tailored solution that suits your unique application.
The delivery time for the equipment depends on various factors, including the availability of stock and the complexity of customization, if applicable. Once we have a better understanding of your requirements, we can provide you with an estimated delivery time. But as a standard will be about 45-60 days which depend on your quantity.
Certainly! We can provide you with references or customer testimonials upon request. Our satisfied customers can share their experiences and provide insights into the quality and performance of our equipment.
We offer comprehensive after-sales support to ensure the smooth operation of the equipment. This includes technical assistance, troubleshooting, and maintenance services. We have a dedicated support team that can address any queries or concerns you may have even after the purchase.
