Stud And Track Roll Forming Machine is fully automatic and high speed machine, Saibo science & technology currently able to achieve a maximum speed is 80m/min. and has high degree of automation, can adjust the roller thickness by servo motor at the same time.
This machine is fully automatic and high speed producing continuously, one set of forming rolls can produce various sizes of Stud and Runner just by simply and easily changing the spacers, this enables the production of different sizes products on the same rollers.if want more fast can change the forming by cassette design.
Is there a problem? Please contact us to serve you!
Stud And Track Roll Forming Machine is fully automatic and high speed machine, Saibo science & technology currently able to achieve a maximum speed is 80m/min. and has high degree of automation, can adjust the roller thickness by servo motor at the same time.
This machine is fully automatic and high speed producing continuously, one set of forming rolls can produce various sizes of Stud and Runner just by simply and easily changing the spacers, this enables the production of different sizes products on the same rollers.if want more fast can change the forming by cassette design.
This machine is also can be designed for in line punching, punching and cutting in one time. Main motor use AC servo motor with inverter, producing in line speed: 60 meter per minute, quick or slow speed can be adjusted freely. After roll forming, automatic in line punching and cutting continuously. Cutting length: from 3 meter to 6 meter or more, length tolerance: within ±1mm. Automatic products piling table is special designed for high speed production capacity and reduce the production cost, create more profit for the customers.
We not only provide Stud/track and different shape profile machine, also can provide the ceiling panel sheet machine.
Stud& track for ceiling is fully automatic and high speed machine, Saibo science & technology currently able to achieve a maximum speed is 80m/min. and has high degree of automation, can adjust the roller thickness by servo motor at the same time. Machine can produce different profiles according to customer request, to save cost, just change the spacers on the shaft, to save the time, can make the cassette type for change.
Main technology
Double head uncoiler for quick change coil
Full automatic change size
Full automatic adjust the roller distance
Non-stop high speed punching and cutting
Full automatic stacking and packing
Main spec. of line:
Layout for reference:
| Forming speed | 60m/min |
| Forming station | about 13 stations |
| Drive | Drive by gear box of each station |
| Full line weight | about 10-15Tons |
| Roller material | D3 |
| Punching die and cutting die material | D2 |
| Motor | Siemens |
| Servo and control system | Mitsubishi/ Siemens/ Panasonic |
Q: What is the price of the roll forming machine?
A: The price of the equipment depends on various factors such as profile specifications, thickness, and additional features. Could you please provide us with more details about your specific requirements, so we can provide you with an accurate price.
Q: What is the warranty period for the roll forming machine?
A: We offer a standard warranty period for our equipment, which typically ranges from one year. However, the exact warranty period may vary depending on the specific equipment model. We can provide you with detailed information regarding the warranty coverage for the equipment you are interested in.
Q: Are spare parts readily available for the equipment?
A: Yes, we ensure that spare parts for our equipment are readily available. We maintain a comprehensive inventory of spare parts to minimise downtime in case of any maintenance or repairs. Additionally, we offer after - sales support and can assist you in procuring any necessary spare parts for a roll forming machine, such as a rolling shutter forming machine, decking sheet roll forming machine, Stud and Track roll forming machine, and so on. Sure, like some rollers need for product depend on order only, it will be 3 - 7 days. We will try our best give you early.
Q: Can you provide training for operating the equipment?
A: Yes, we can provide comprehensive training for operating the equipment. Our team of experts will guide you through the installation process and provide hands - on training to ensure that you and your staff are familiar with the equipment's operation, maintenance, and safety procedures.
Q: Is installation included in the purchase price?
A: The inclusion of installation services may vary depending on the specific equipment and the location of the installation. We can discuss the installation options available and provide you with a detailed quotation that specifies whether installation is included or if it will incur additional charges.
Q: Do you offer customization options for the equipment?
A: Yes, we do offer customization options for our equipment to meet specific customer requirements. We can discuss your customization needs and work closely with our engineering team to develop a tailored solution that suits your unique application.
Q: What is the expected delivery time for the equipment?
A: The delivery time for the equipment depends on various factors, including the availability of stock and the complexity of customization, if applicable. Once we have a better understanding of your requirements, we can provide you with an estimated delivery timeframe. But as standard will be about 45 - 60 days with depend on quantity request.
Q: Can you provide references or customer testimonials for your equipment?
A: Certainly! We can provide you with references or customer testimonials upon request. Our satisfied customers can share their experiences and provide insights into the quality and performance of our equipment.
Q: What after - sales support do you offer?
A: We offer comprehensive after - sales support to ensure the smooth operation of the equipment. This includes technical assistance, troubleshooting, and maintenance services. We have a dedicated support team that can address any queries or concerns you may have even after the purchase.
